Precision　Products

Precision components

Utilizing our precision machining techniques cultivated through the experience in optical communications, SHP is ready to meet your needs such as:

We will expand our abilities by challenging any material and configuration.
Also, we are willing to machine parts for industries other than optical communications.

Examples of our products

Features

Hard-to-cut materials Kovar, SUS304, SUS304L, SUS316L, and other materials
Small hole drilling More than Φ0.3 mm
Accuracy - Inner diameter tolerance (more than Φ0.8 mm): 3 µm (currently challenging for 1 µm)
- Concentricity: less than Φ0.01 mm
- Thickness of inner/outer diameter: more than 0.1 mm
- Total length: more than 0.1 mm
- Flatness: less than 0.01 mm
- Perpendicularity: 0.001 mm to 0.01 mm
Multiple machining One-chucking solution improves machining accuracy and enables quicker delivery and lower prices.
Lead time Prototype available to ship within one week.
Quotation Able to provide by 5:00 p.m. the next day if we receive the design by 3:00 p.m.
Quantity Up to 10,000 pcs. (more than 10,000 pcs. also acceptable)
